Immerse in Golf Without Space Limits
The AH30ST projector fits small spaces and low ceilings, delivering vivid colors and effortless setup for an authentic golf simulation at home.
All Specifications
Display
Brightness (ANSI lumens) 3000
Resolution 1080P (1920x1080)
Native Aspect Ratio 16:9
Contrast Ratio (FOFO) 20,000:1
Display Color 30-bit (1.07 billion colors)
Light Source 4LED
Light Source Life a. Normal 20000 hrs, b. ECO 30000 hrs
Optical
Throw Ratio 0.69-0.83
Zoom Ratio 1.2x
Lens F = 2.6 ~ 2.78 f = 10.2~12.24 mm
Projection Offset (Full-Height) 102.5%
Keystone Adjustment 2D, (Auto) Vertical ± 30 degrees; Horizontal ± 30 degrees
Rec. 709 Coverage 95%
Picture Modes 3D, Bright, Cinema, Game, Golf, sRGB, User 1, User 2
Compatibility
Input Lag 16.7 ms (1080P 60Hz)
Resolution Support VGA(640 x 480) to WUXGA_RB(1920 x 1200) *RB=Reduced blanking
Horizontal Frequency 15K~135KHz
Vertical Scan Rate 23~120Hz
I/O Interface
HDMI in HDMI-1 (1.4a/HDCP1.4), HDMI-2 (1.4a/HDCP1.4)
USB Type A (x2), USB Type A-1 (2.0/Power Supply1.5A), USB Type A-3 (2.0/Wireless Dongle)
RS232 in (DB-9pin) (x1)
Audio
Speaker (x1)
10W Audio out (3.5mm Mini Jack) (x1)
Environment
Operating Temperature 0~40℃
Power Supply AC 100 to 240 V, 50/60 Hz
Typical Power Consumption (110V) 237W
Stand-by Power Consumption <0.5W
Acoustic Noise (Typ./Eco.)(dB) 32dBA/28dBA
Accessories
Wireless USB dongle EZC-5201BS 1080p, (Optional)
Remote Control w/ Battery RCX016
Power Cord (by region) x1 (1.8M)
3D Glasses DGD5, (Optional)
Quick Start Guide (x1) 1L
Warranty Card (by region) Yes
Lens cover Yes
Universal Ceiling Mount CM00G3, (Optional)
Dimension & Weight
Dimensions (WxHxD) (mm) 303.5*107.4.*220.7
Net Weight (kg) 2.65
Dimensions (WxHXD) (inch) 11.95*4.23*8.69
Net Weight (lb) 5.84
Projection System
Projection System DLP
